The FSI LM-0950W is a lightweight color critical high resolution 9" Multi-Format LCD monitor with 3G/HD/SD-SDI, Component (YPbPr/RGB), Composite, and DVI-I Inputs. This unit is packed with many common broadcast monitor features like Blue Only, MonoChrome, Markers, Safety Areas, & Tally Lights and like all FSI monitors it also comes standard with advanced 12 Mode Scopes, Focus Assist, Timecode Display, LUM Coloring Exposure Check, Freeze Frame Picture and Picture, Audio Disembedding, and Audio Level Meter features. The LM-0950W is ready for virtually any application with instantly adjustable Gamma & Color Temperature Presets and true Multi-Format support ranging from NTSC/PAL to HD and 2K. Additionally, the LM-0950W comes standard with 3Gbps SDI Inputs for support of 1080p50/60 and 4:4:4 signals over a single Serial Digital Interface. The LM-0950W is also capable of additional Level B 3Gbps SDI monitoring modes as explained here. The LM-0950W comes with a 12VDC 4 pin XLR power connection as well as your choice of AB Gold Mount or V-Mount battery plates. The ultra-efficient LED backlight allows the unit to draw only 15W of power and thanks to its lightweight yet durable aluminum chassis the monitor's weight, with battery plate, is a mere 3 lbs (1.36 kg) making it ideal for field use. Also take a look at our LM-0950W Field Package, which includes the monitor, a clear protective lcd panel cover, carrying bag with integrated hood, 6' Mini-HDMI to DVI Cable, and 6' RG6 BNC cable all for one low price: LM-0950W.FieldPkgThe LM-0950W is compatible with many popular HDSLR cameras that have HDMI or mini-HDMI outputs. Simply use the LM-0950W in conjunction with a HDMI to DVI or mini-HDMI to DVI cable to easily pair it up with your DSLR. The LM-0950W can be rack mounted (5RU) in a single or dual mount configuration. Additionally, the LM-0950W comes with standard 1/4-20 threaded mounts top and bottom for camera top mounting. Perfect as a compact field or studio monitor the LM-0950W packs all of the features of the larger FSI monitors into a compact, lightweight, yet durable design.
LM-0950W Promo Video: High Level Overview
All FSI Monitors come with a standard 2 year warranty parts and labor. All Quoted FedEx Shipping Rates include shipping insurance. See our Terms and Conditions for Details on our Return Policy. International orders (any orders shipping outside of the US) are generally subject to local import duties and taxes. For more information on International Shipping see our Help/FAQ.
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- High Resolution (1024x600) native 8 bit LCD panel (16.7 Million Colors)
- 60% Higher Resolution than 7" LM-0750W
- Ultra-Low Power Consumption: 15W@120nit, 17W@275nit
- Lightweight: 3 lbs / 1.36 kg (includes battery plate weight)
- Vertical Image Flip Mode
- Standard 3Gbps SDI Inputs Included for Support of Advanced SMPTE 425M-AB Signals
- Timecode Display (VITC 1, VITC2, LTC)
- Automatic Source Resolution & Frame Rate ID: toggle on, off, or temporary 5 second display when format change is detected or input button is pressed
- DSLR Zoom feature for full screen scaling of DSLR video source at both 480 and 1080 resolutions
- On-Screen Alarms (IRE Threshold, RGB Alarms, Loss of Signal, Audio Mute, and more)
- Front and Rear (talent) Tally Lights
- Adjustable Focus Assist (Focus Meter and Focus Highlight in Red)
- Wide Variety of Standard Markers & Safety Areas
- Pixel Zoom Feature - High Quality Adjustable Zoom on any portion of HD signal
- CX Scale (video example): Full Screen and centered scaling of Codex ARRIRAW Recorder output
- User Adjustable Custom Marker Feature
- Active Video Boundary Marker
- H/V Delay
- Blue Only
- Monochrome
- HD Anamorphic De-Squeeze (1.3x, 2.0x, 2.0xMag)
- AFD Reader
- Overscan/1:1 scan
- Freeze Frame Picture by Picture
- 12 Mode Scopes (Luminance Waveform, Vector Scope, RGB Parade, GBR Parade, RGB Overlay, YRGB Peak Column, Histogram, Color Histogram, RGB Histogram, YCbCr, YCbCr Overlay, & Audio Phase Meter)
- Audio Disembedding
- Audio Level Meters
- Color Temperature Selection
- Gamma Selection (1.0~2.8)
- SD Aspect Ratio Selection (Anamorphic/4:3)
- Advanced Measurement Feature
- Exposure Level Indication with LUM Coloring feature
- Remotely Controlled Front and Rear (Talent) Tally Lights (Red/Green/Amber)
- DC (4 Pin XLR), Battery (V-Mount or Gold Mount), and AC (with adapter) operation
- Diecast Aluminum Frame
The following Scope Modes are available on all inputs (any 2 may be viewed simultaneously):
 *Audio Phase Meter only on HD/SD-SDI sources.
Audio Level Meter Feature:
Allows up to 16 channels of audio to be monitored on screen. These will be displayed at the top of the screen or can be viewed at the bottom of the screen simultaneously with the Waveform/Vector Scope feature.
Top
Bottom
|
|
|
|
|
|
|
|
