This bundled field package is a great way to save money and includes the following items: - LM-2140W: Flanders Scientific 21.5" Broadcast Monitor (without desktop stand)
- CBH21: Carrying Bag with Integrated Hood for LM-2140W
- CPC21: Clear Protective Screen Cover for LCD Panel
- MM20: VESA to Light Stand Mount
LM-2140WThe LM-2140W is a 21.5" calibrated professional monitoring solution ideally suited for onset/field applications. The 21.5" LM-2140W was purpose built as a full-featured low cost monitoring solution for environments that do not require the performance of FSI's flagship LM-2461W.
The LM-2140W features a full native HD 1920x1080 resolution IPS LCD panel with a power efficient white LED backlight. Additionally, this unit comes standard with 3Gbps/HD/SD-SDI, Component, Composite, and DVI-I Inputs for support of virtually any video format including NTSC/PAL, 4:4:4 signals, 2K, and 1080p50/60 sources. The LM-2140W is also capable of additional Level B 3Gbps SDI monitoring modes as explained here.
The LM-2140W also features many standard broadcast monitor features like Blue Only, Monochrome, Markers, Safety Areas, & Tally Lights. Like all FSI monitors it also comes standard with advanced features like our 12 Mode Scopes, Focus Assist, Time Code Display, Freeze Frame Picture and Picture, Audio Disembedding, and Audio Level Meter features.
CBH21 The CBH21 is a custom carrying case
that provides ample protection for your monitor with a single piece
honeycomb frame and foam padding coupled with a durable cordura and
ballistic nylon exterior. This carrying bag also features a built in
hood that can be used in both a 3 sided and 4 sided configuration for
maximum shade in brighter environments.
The
easy access zippered back panel provides quick access to the monitor as
well as two large accessory pockets perfect for battery or cable
storage. At the back of the monitor you will also find the adjustable
back support leg that allows you to position the monitor for optimal
viewing. This back support leg can also be lifted for access to the
LM-2140W’s VESA mounting points, where the MM20 VESA to Light Stand Mount included as part of this field kit will be attached. Best of all the CBH21 has been designed with enough
depth to allow you to leave the MM20 attached at all times, even when
the bag is closed for transport.
The
monitor is held in the bag with two quick release straps allowing the
unit to be installed or removed from the bag quickly and easily. The
straps feature a unique AccuSlide system allowing the straps to be
positioned so as not to interfere with any input or power connectors.
The
CBH21 comes with a removable padded shoulder strap for easy
transportation. The case is also quite compact and at just 8.8 lbs is
extraordinarily lightweight. The combined weight of the LM-2140W and
CBH21 is just 17.8lbs, which is actually over half a pound lighter than a
comparable configuration utilizing a 17” FSI monitor and similar
Carrying Bag with Integrated Hood.
CPC21 This is a clear protective cover for the front of the LM-2140W. The
cover's primary function is to prevent damage to the LCD panel,
especially from fingers that may poke and prod at the screen. The cover
simply velcros (provided) to the front of the monitor and is easily
removable. This realtively inexpensive clear cover is an easy way to
safeguard the LCD panel and is much less expensive to replace if it gets
scratched or damaged than replacing the LCD panel itself.
The
CPC21 is made of a very neutral optical grade acrylic that is scratch
resistant and extremely lightweight. The CPC21 cover is custom cut to
fit onto the LM-2140W. We recommend the CPC21 for field use and onset
applications, but not for edit suites.
MM20
The MM20 is a Lightweight VESA to 5/8" spigot
adapter and is a perfect solution for mounting your LM-2140W, to a light stand for studio and on location
shoots. This lightweight mount is adjustable with 2 pivot points
allowing for quick and easy positioning of the monitor for ideal
viewing. This mount ttaches directly to the VESA mounting points on the back of
the monitor and to any 5/8" male spigot light stand.
This adapter is made of durable aircraft grade anodized aluminum and can support up to 40lbs of weight. Additionally, the mount folds up conveniently inside of the CBH21 so the mount does not have to removed during transport or when not in use. |
Carrying Bag with Integrated Hood Product Overview
LM-2140W Product Overview Video
FSI Monitors come with a standard 2 year warranty parts and labor. All Quoted FedEx Shipping Rates include shipping insurance. See our Terms and Conditions for Details on our Return Policy. International orders (any orders shipping outside of the US) are generally subject to local import duties and taxes. For more information on International Shipping see our Help/FAQ.
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Lightweight: Complete package weighs less than 20 lbs (9kg)
- Monitor: 9 lbs / CBH21: 8.8 lbs / MM20: 1 lb
- Native 1920x1080 Resolution HD LCD Panel
- 10 Bit Video Processing, 8 Bit LCD Panel (16.7 Million Colors)
- Ultra-Low Power Consumption: 28W@120nit, 37W@250nit
- Standard 3Gbps SDI Inputs Included for Support of Advanced SMPTE 425M-AB Signals
- Timecode Display (VITC 1, VITC2, LTC)
- Automatic Source Resolution & Frame Rate ID: toggle on, off, or temporary 5 second display when format change is detected or input button is pressed
- DSLR Zoom feature for full screen scaling of DSLR video source at both 480 and 1080 resolutions
- On-Screen Alarms (IRE Threshold, RGB Alarms, Loss of Signal, Audio Mute, and more)
- Adjustable Focus Assist (Focus Meter and Focus Highlight in Red)
- Wide Variety of Standard Markers & Safety Areas
- Pixel Zoom Feature - High Quality Adjustable Zoom on any portion of HD signal
- CX Scale (video example): Full Screen and centered scaling of Codex ARRIRAW Recorder output
- User Adjustable Custom Marker Feature
- Active Video Boundary Marker
- H/V Delay
- Blue Only
- Monochrome
- HD Anamorphic De-Squeeze (1.3x, 2.0x, 2.0xMag)
- AFD Reader
- Overscan/1:1 scan
- Freeze Frame Picture by Picture
- 12 Mode Scopes (Luminance Waveform, Vector Scope, RGB Parade, GBR Parade, RGB Overlay, YRGB Peak Column, Histogram, Color Histogram, RGB Histogram, YCbCr, YCbCr Overlay, & Audio Phase Meter)
- Audio Disembedding
- Audio Level Meters
- Color Temperature Selection
- Gamma Selection (1.0~2.8)
- SD Aspect Ratio Selection (Anamorphic/4:3)
- Advanced Measurement Feature
- 3D Signal Analysis Modes for multiplexed Level B 3Gbps SDI signals: Left Eye, Right Eye, Picture and Picture, Horizontal Split (with adjustable split position), Vertical Split (with adjustable split position), 3D Disparity, 3D Line By Line, 3D Checkerboard with adjustable Checkerboard size. *The LM-2140W is not a 3D display, these modes are strictly diagnostic modes for 3D signal analysis.
- Exposure Level Indication with LUM Coloring feature
- Remotely Controlled Tally Lights (Red/Green/Amber)
- AC and DC (12 VDC 4 Pin XLR) Operation
- Durable Aluminum Frame
The following Scope Modes are available on all inputs (any 2 may be viewed simultaneously):
 *Audio Phase Meter only on HD/SD-SDI sources.
Audio Level Meter Feature:
Allows up to 16 channels of audio to be monitored on screen. These will be displayed at the top of the screen or can be viewed at the bottom of the screen simultaneously with the Waveform/Vector Scope feature.
Top
Bottom
|
|
|
|
|
|
|
|
